Endurance High-Temperature Infrared RatioPyrometer

Endurance High-Temperature Infrared RatioPyrometer - Fluke Process Instruments GmbH

Endurance High-Temperature Infrared RatioPyrometer

Pyrometers

Ask for a quote

Presentation

Broad temperature range 50 to 3200°C
4-year warranty
Durable IP65 (NEMA4) housing

Visible through the lens sighting and manual variable focus plus optional laser sighting, video camera, or LED sighting

LAN/Ethernet interface with PoE for sensor communication (ASCII, Video, and Webserver)
Profinet interface option
Programmable relay output
Fail-safe alarm
Isolated analog input/output
Rugged stainless-steel housing
Dirty-window alarm
Endurance software for remote configuration, remote monitoring, and field calibration

In addition to single-color models, the series also comprises two-color (ratio) pyrometers and models with a remote sensor head (Endurance Glass-Fiber).

APPLICATIONS
Metals: forging, hot rolling, rod/wire production
Heat treating & annealing
Induction heating
Lightbulb and halogen lamp production
Glass melting
Semiconductor furnaces
Cement & lime kilns
Refuse burning
Carbon graphite production
Foundry & welding
Rubber & thick plastic

Technical features

Measured temperature range monochrome models: 50 – 3200 °C (depending on model) Ambient temperatures: Up to 65 °C, up to 315 °C (600 °F) with ThermoJacket enclosure Optical resolution: Up to 300:1 Ingress protection: IP65 (NEMA 4) Spectral response: 1.0 μm, 1.6 μm, or 2.4 μm depending on model Accuracy: From ±0,3% / ±2 °C Resolution: 0.1 °C Response time: 2 ms, 20 ms (95%) Power supply: 20 – 48 VDC, 500 mA or Power over Ethernet (PoE) Digital outputs: Ethernet, Profinet

Download the complete technical features
