Machining centre C 400

Compensators of PRONALUsually mounted inside hydraulic tanks and operating without an energy source, these products compensate for variations in the volume of oil or other fluid due to changes in...

Ask for a quote

Presentation

The C 400 is a dynamic machining centre offering perfect entry into 5-axis/5-side machining. The C 400 machining centre is based on HERMLE's proven core expertise in 5-axis technology. Powerful and dynamic - it reliably meets the demands of the market - precisely and convincingly.

The mineral casting machine bed promotes stable, vibration-free machining.

The C 400 features a large working area with a small installation area and can be ergonomically adapted to every machine operator - thus ensuring optimum ease of use.

Numerous features ensure cost-effective production. The C 400 machining centre is intended for high performance, large-scale machining of workpieces to high accuracy and surface quality.

Technical features

Traverse X-axis: 850 mm Traverse Y-axis: 700 mm Traverse Z-axis: 500 mm Rapid linear traverses X-Y-Z: 35-35-35 m/min Linear acceleration X-Y-Z: 6 m/s² Linear feed force X-Y-Z: 7000 N Max. vertical table clearance: 625 mm Max. workpiece diameter: Ø 650 mm Max. workpiece height: 500 mm Collision circle (A axis) in 0° position: Ø 885 mm

Download the complete technical features
