Designed for machining cubic parts up to 100 kg in weight, the C12 works in the most diverse applications compactly, precisely and dynamically. The C 12 is more than a match for larger models. Aside from its compact size, the main focus is on HERMLE's core competences precision, durability and dynamics. Designed as a 5-axis machining centre featuring the different spindle speeds and different interfaces, the ideal speed is available for almost every area of application.
The C 12 can be equipped with two-piece ore compact spindles. All tool spindles can be replaced quickly and easily in case of failure.
Thanks to the respective HERMLE set-ups, the C 12 also meets the ever increasing requirements placed on speed and precision. The C 12 machining centre additionally provides extensive options for more intricate applications.
Traverse X-axis: 350 mmTraverse Y-axis: 440 mmTraverse Z-axis: 330 mmRapid linear traverse (dynamic) X-Y-Z: 30 (50) m/minLinear acceleration (dynamic) X-Y-Z: 4 (8) m/s²Linear feed force X-Y-Z: 3000 NMax. vertical table clearance: 430 mmMax. workpiece diameter: Ø 320 mmMax. workpiece height: 265 mmCollision circle (A axis) in 0° position: Ø 610 mm
