The C 650 uses a modification of HERMLE's tried-and-tested gantry-type design, with a mineral-cast machine bed. The integrated, rigid clamping table can cope with workpieces up to a maximum of 3000 kg (1050 x 900 x 600 mm) in the 3-axis version, making it ideal for toolmaking, mould construction and machine construction. The swivelling rotary table of the 5-axis version can accommodate workpieces up to 1500 kg (Ø 900 x 600 mm), allowing for highly precise machining.
The traverse path in the stainless-steel-clad working area comprises 1050 x 900 x 600 mm with a vertical table clearance of 775 mm and a door aperture of 1050 mm. Ideal parameters for simple and safe crane charging.
The C 650 has an integrated tool magazine for 42 tools. The control panel of the C 650 is also designed to swivel easily to the magazine loading location, so the operator can enter the tool data directly into the tool table in the control system.
Traverse X axis: 1050 mmTraverse Y axis: 900 mmTraverse Z axis: 600 mmRapid linear traverses X-Y-Z: 35 - 35 - 35 m/minLinear acceleration X-Y-Z: 6 m/s²Linear feed force X-Y-Z: 7000 NMax. vertical table clearance: 775 mmMax. workpiece diameter: Ø 900 mmMax. workpiece height: 600 mmCollision circle(A axis) in 0° pos.: Ø 1100 mm
