The C 52 is intended for the simultaneous 5-axis machining of workpieces weighing up to 2000 kg - with unbeatable accuracy and precision. Parameters that always represent a challenge for the machine dynamics. HERMLE has overcome these challenges by developing and designing a precise and high-performance machining centre. The C 52 is the successor of the extremely successful C 50.
The C 52 machining centre: A flexible all-rounder with a large working area and minimum footprint. The tool magazine of the C 52 is also integrated and can be extended to 325 pockets using an additional magazine.
The C 52 sets new standards: These standards are particularly valued in demanding applications, for instance in the medical, aerospace and automotive industries. In short: wherever the highest precision and maximum efficiency are required.
Milling and turning in one clamping - the MT series with the model C 52 U MT dynamic.
Traverse X-axis: 1000 mmTraverse Y-axis: 1100 mmTraverse Z-axis: 750 mmRapid linear traverses X-Y-Z: 60-60-55 m/minLinear acceleration: 6 m/s²Linear feed force X-Y-Z: 16000 NMax. vertical table clearance: 950 mmMax. workpiece diameter: MT: Ø 1000 mm 5-axis: Ø 1100 mmMax. workpiece height: 810 mmCollision circle (A axis) in 0° position: Ø 1290 mm
