Machining centre C 42

Milling unit

Ask for a quote Receive Documentation Contact the supplier

5-axis/5-sided machining means the C 42 lends itself to be used in every application area.
With traverse paths adapted to the workpiece size and perfectly designed for 5-axis applications, the C 42 is ideal wherever complex, close-tolerance components are required.

This includes various applications in the tool and mould making, medical, aerospace, motorsport, machine sectors and other industries: The C 42 machining centre is at home in every area.

The space-saving circular tool magazine integrated into the base body of the machine works according to the pick-up principle - thus enabling quick tool changes. In the standard version, the C 42 can hold 42 tools and can be extended to 192 pockets. The control panel can be easily adjusted to the respective user.

Milling and turning in one clamping with the C 42 U MT dynamic model. Fully integrated rotary table that does not interfere with demanding milling processes and 5 axes simultaneously.

Traverse X-axis: 800 mm Traverse Y-axis: 800 mm Traverse Z-axis: 550 mm Rapid linear traverse (dynamic) X-Y-Z: 45-45-40 m/min (60-60-60 m/min) Linear acceleration (dynamic) X-Y-Z: 6 (10) m/s² Linear feed force X-Y-Z: 8500 N Max. vertical table clearance: 700 mm Max. workpiece diameter: Ø 800 mm Max. workpiece height: 560 mm Collision circle (A axis) in 0° position: Ø 990 mm
Download the complete technical features
