Copy milling machine - FC 380 SL

Milling on 3 sides of a profile by swiveling 180 ° (without loosening the profile) by template or stop system with calibrated milling cutters.

This machine mounted on fixed frame is equipped with :

. TRI 400 V motor, power 0.45 / 1.1 kW.
. 2 spindle speeds 3500 and 10500 rpm.
. Milling head.
. Profile maintained by 4 horizontal cylinders and 4 vertical cylinders on a cradle support. The profile can rotate from 0° to 180° (indexed by 90 °) on its axis. Pneumatic locking in position with low pressure valve.
. Movement in rotation studied so that the positioning of the machining does not change at 0 ° and 180 °.
. Two-handed operation for fast raising of the milling head, as well as slow descent, adjustable milling head (hydropneumatic ram). Thanks to a system of stops, one can obtain fast approaches and slow work displacements.
. 2 control handles for manual movement of the milling head in the horizontal plane.
. Start the spindle motor by simultaneously pressing both trigger handles.
. 2 adjustable depth stops.
. Template with 1 copy finger Ø 5/6/8 mm.
. 3 collets Ø 6/8/10 mm.
. Spray lubrication system.
