Coilers with cranks

EM050

Without plugs

Galvanised steel
Rigide and stable chassis
Cahoutchouc carrying handle
Drum in heavy plate, stamped, unbreakable

Capacity
70 metres of a Ø 5 mm cable
or
50 metres of a Ø 10 mm cable

Dimensions
Diameter of the flanges : 280 mm
Diameter of the drum : 105 mm
Usable width : 90 mm

Space requirement
L 280 x D 185 x H 360 mm
Weight : 1,7 kg

EM050P

With plugs, with flask ok undrilled closure

Galvanised steel
Rigide and stable chassis
Cahoutchouc carrying handle
Drum in heavy plate, stamped, unbreakable

Capacity
70 metres of a Ø 5 mm cable
or
50 metres of a Ø 10 mm cable

Dimensions
Diameter of the flanges : 280 mm
Diameter of the drum : 105 mm
Usable width : 90 mm

Space requirement
L 280 x D 185 x H 360 mm
Weight : 1,7 kg

EM060

Capacity : 60 metres of a Ø 10 mm cable
Steel frame
Plastic drum

Capacity
100 metres of a cable Ø 7 mm
or
60 metres of a cable Ø 10 mm
or
30 metres of a cable Ø 15 mm

Dimensions
Diameter of the flanges : 275 mm
Diameter of the drum : 100 mm
Useable width : 105 mm

Space requirement
l 280 x P 190 x H 365 mm
Weight : 1,2 kg
Model Code : EM060
Old Code : EM22
Space requirement : l280 x P190 x H365 mm
Weight : 1.2kg

Ø of flanges : 275mm
Ø of the drum : 100mm
Useful width : 105mm

Plugs : -
Wheels : -

Material : Steel frame, plastic drum
Indicative capacity based on cable Ø : 100m (7mm) / 60m (10mm) / 30m (15mm)

Code EM060

EM100

Code : EM100 / EM100R

Space requirement : l550 x P380 x H625 mm

Weight : 17kg
Ø of flanges : 475mm
Ø of the drum : 250mm
Useful width : 290mm

Plugs : -
Wheels : Delivered with 4 casters Ø 80 mm (only for EM100R)
Material : Epoxy finish steel frame and flanges
Indicative capacity based on cable Ø : 100m (10mm) / 57m (15mm) / 42m (20mm) / 21.5m (30mm)

EM230 - EM230R

Code EM230 / EM230R

Space requirement : l540 x P440 x H465 mm
Weight : 13.85kg (EM230) / 16.35kg (EM230R)

Ø of flanges : 398mm
Ø of the drum : 150mm
Useful width : 350mm

Plugs : -
Wheels : Delivered with 4 casters Ø 100mm, of which 2 with locking mechanism (only for EM230R)
Material : Epoxy finish steel frame and flanges
Indicative capacity based on cable Ø : 230m (10mm) / 150m (15mm) / 80m (20mm) / 36m (30mm)

EM320 - EM320R

Code EM320 / EM320R

Space requirement : l680 x P440 x H465 mm
Weight : 14.4kg (EM320) / 16.9kg (EM320R)

Ø of flanges : 395mm
Ø of the drum : 147mm
Useful width : 485mm

Plugs : -
Wheels : Delivered with 4 casters Ø 100mm, of which 2 with locking mechanism (only for EM320R)
Material : Epoxy finish steel frame and flanges
Indicative capacity based on cable Ø : 320m (10mm) / 210m (15mm) / 120m (20mm) / 52m (30mm)
