Abrasive disc automatic die cutting press - SYSCO - ABR

With the compact SATO CT4-LX thermal transfer label printer, you can print high-quality roll labels yourself—individually or in sequence. The label print quality is comparable to the pre-printed...

Ask for a quote

Presentation

Three sets of servo motor position systems, position accuracy +/-0.2mm.
Working capacity up to 57 600 pieces of abrasive disc per 8 hours with two cavity cutting die to cut two plies of roll material.
User friendly computer control and 100 cutting program memory provides easy operation.
Punch-slugs go through punch tube to slug box under head and you can use a vacuum cleaner to clear out the slugs.
Cut part auto knock out & stacking system will stack cut parts to preset quantity ready to be packed. This function can save several workers.
Auto cutting directly from jumbo rolls can not only simplify manufacturing process, but also achieve material savings up to 15%.
Unique stainless steel grid plate feeding device & stacking system can achieve perfect feeding & stacking results for all kinds of non-woven felt, Velcro backing, and pressure sensitive adhesive(PSA) release paper backing of abrasive sandpaper material.
Separate sealed hydraulic unit with external line filter and seal-protected moving parts protects against abrasive entry and can provide excellent machine durability.
Unique function cuts deeper automatically to compensate for worn-out die blade edges and obtains excellent clean cut parts.
Motorized 4 post mechanical stops stroke control device allows the cutting die to just touch the cutting surface and therefore can provide excellent die and pad life.
P.P. pad shifter device can save cutting pad cost and provides clean cut parts.

Technical features

Cutting force : 30 t / 40 t Open daylight 210-80 mm / 210-100 mm Cutting head : 500x500 mm / 600 x 650 mm Machine bed : 500Dx2100W (mm) / 760Dx2500W (mm) Dimensions : 6200L x 2850 W x 2100 H(mm) / 8860L x 5500 W x 2470 H(mm) Weight : 3700 / 9000 kg Motor : Main : 5HP Servo: 2HPx2 / Main: 7.5HP Servo: 2HPx3
