High speed hydraulic die cutting press on stainless steel table : SYSCO - HSC

High speed hydraulic die cutting press on stainless steel table : SYSCO - HSC - DOREY

High speed hydraulic die cutting press on stainless steel table : SYSCO - HSC - Cutting press

High speed hydraulic die cutting press on stainless steel table : SYSCO - HSC - produit présenté par DOREY

High speed hydraulic die cutting press on stainless steel table : SYSCO - HSC

Cutting press

Ask for a quote

Presentation

Mono Hydraulic cylinder
Cutting stroke 110 mm
4 manual or motorized mechanical stops accuracy +/- 0.01 mm
Through cut and kiss cut on hardened steel plate 60 HRC Picard accuracy +/- 0.01 mm
Slow down stroke: 10mm before touching the material
Fast die change
Touchscreen control in different languages
Standard electrical, hydraulic and pneumatic parts
Safety guards and/or photocells Class 4
Meets CE

Technical features

Cutting force : 25 T Cutting stroke : 130 mm Max. open daylight : 155 mm Min. open daylight : 25 mm Head : 500x500 / 650x650 mm Maximum blank size : 500x500 / 650x650 mm Motor : 5HP Dimensions : 3300Wx1500Dx2030H mm Net waight : 3500 kg
