XVC-1000e/1100e HDR vision cameras for welding and additive manufacturing

“ - Complete camera with rugged housing, lighting, motorized focus and protective glass - Very high dynamic range image140dB (no saturation) - Version with color allows to see both the arc and the scene (weld pool, heat affected zone) with high quality - Camera with embedded FPGA for image processing - Opto-isolated GPIO (no external disturbance from surrounding power supplies or motors) ”

Ask for a quote

Presentation

The XVC-1000e/1100e series of all-digital HDR welding cameras is designed to monitor all open arc welding processes for OEMs, advanced end users or laboratory environments.
These turn key cameras can address the TIG/GTAW, MIG/GMAW, stick welding, plasma or laser markets.

Based on the XVC-1000/1100 cameras, it integrates lighting, motorized focusing device, splash protection window and air or water cooling in a housing specially designed for the welding environment.

It offers the following key features:
- High dynamic range images (HDR 140dB) in monochrome (XVC-1000e) or color (XVC-1100e).
- Remote monitoring up to 100 meters
- C/CS mount for custom optics
- Up to 55 fps @ 1280 x 1024 pixels in 8 or 12bit
- PoE interface

It comes with WeldStudio software running under Windows 7, 8 or 10 that allows you to control camera settings, capture images and make video recordings.

Technical features

2/3 inch HDR CMOS monochrome (XVC-1000e) or color (XVC-1100e) IR + UV filter Dimensions: 51x51x179mm 15 +/-1V nominal via GPIO interface 15W max Output in GiGE 8 or 12 bits or UART Camera synchronization via software or external trigger Weight: 600g Cables up to 100m CE, FCC-B and RoHS compliant
