Strap Cutting Machine with Cut to Length : ANT-TTE-DIGIT

Blade cutter

Ask for a quote

Presentation

The T.T.-E digt is an electro-pneumatic cutting machine with small dimensions also suitable for installation in places with limited space such as workshops.

The electricity supply at 230V single-phase and the low consumption of compressed air contribute to a still more easy to install.

The sectors of use are varied: textile, leather, footwear, etc. wherever you need to cut materials length as: rubber bands, ribbons, laces, drawstrings, zippers, velcro, straps, shoulder straps, mignon, belts.

Depending on the machine configuration, it can cut:

By cold with scissors blades made of tempered steel and self-sharpening cutting light with a maximum of 120 mm;

By heat with a heated knife by low voltage electrical resistance, the cutting takes place by thermal fusion (only suitable for synthetic materials) with a 110 mm cutting light and can be equipped with an automatic device for inclined cut;

By cold and heat, used separately, directly selectable from the electronic programmer.

Technical features

Dimensions : 950X1300X460 (h) mm Weight : 86 kg Power consumption : 850W (hot cutting) - 400W (cold cutting) Compressed air : cold cutting 0.52 Nl per cycle - hot cutting 1.21 Nl per cycle Cold Cutting Light : 120 mm Hot cutting light : 110 mm Minimum cutting length : 0.1 mm Maximum cutting length : 100 meters Material transport speed : adjustable max 80 cm / s
