Smart laser triangulation displacement sensor

Laser position sensors

“ Unique ease of use All optoNCDT 1420 models are operated using an intuitive web interface. Presets and a quality slider for the selection of the measurement task enable the sensor parameter set up. Up to eight user-specific sensors settings can be stored and exported in the setup management. Set ups can be quickly and easily saved, loaded and transferred to further sensors. The video signal display, the signal peak selection and a freely adjustable signal averaging enable to additionally optimize the measurement tasks. The ROI function (region of interest) allows e.g. for interfering signals in the background to be filtered out. The multifunction button enables quick sensor commissioning for easier measurement tasks. ”

Ask for a quote

Presentation

The optoNCDT 1420 offers a unique combination of speed, size, performance and application versatility in the class of compact triangulation sensors. The sensor is equipped with an integrated controller and achieves high measurement accuracy at measuring rates of up to 4 kHz. The selectable connector type (cable or pigtail) minimizes the installation effort for the sensor. The Active Surface Compensation (ASC) provides stable distance signal control. The high-performance optical system projects a small light spot onto the target which enables the reliable detection of even the smallest of components and details. Analog and digital output signals enable the sensor to be integrated into plant and machine control systems.

All optoNCDT 1420 models are operated using an extended web interface. The settings for the measurement task can be quickly selected using predefined presets. The quality slider enables the sensor to be adapted to static and dynamic processes. Up to eight user-specific sensor settings can be stored and exported in the setup management. The video signal display, the signal peak selection and a freely adjustable signal averaging enable optimization of the measurement task. The ROI function (region of interest) allows, e.g., for interfering signals in the background to be filtered out. The remaining signal peak is optimally corrected.

Technical features

Ideal for serial and OEM applications Compact design with integrated controller Measuring rate up to 4kHz Analogue (U/I) and digital output Trigger input / teach-in / zero-setting / mastering Configuration via web interface or Plug & Play Application-specific presets and individual setups Auto Target Compensation

Download the complete technical features
