Machining Centre: TK 427N

The TEKNA Model TK 427N 4 axis CNC vertical Machining Centre is designed for drilling, convenThe TEKNA Model TK 427N 4 axis CNC vertical Machining Centre is designed for drilling, conventional milling and copy milling operations on aluminum profiles and other materials including steel profiles up to 5 mm thick, plain or steel reinforced PVC profiles, and various other plastics or wood.

Special fabricated and weined steel bed frame with finish machinend, linear recirculating ball slideways on X axis. Double precision rack and pinion axis motion driven by brushless motor with a rapid travers rate of 80 m/1’.

Bridge type gantry assembly with cast structural beams that include finish machined, Y and Z axis linear recirculating ball slideways. Recirculating ball screw (Y) and precision rack (Z). Motion driver by brushless motors with a rapid-traverse rate of 30 meters per minute (Y) and 40 meters per minute (Z).

Mist coolant system utilizing micro-drop technology.

Twin - machine divided into two areas for lengths from 6200 on. While the unit is machining on one side, the operator can safely load/unload the second work area thus reducing set up time increasing productivity.

Ports USB, Lan, Modem. External protection net.
