The machining centres TK 419/3 are compact machine with remarkable capacity to work. Work capacity on X: 3200 mm, work capacity on Y: 1600 mm. The machining centers TK 419/3 are characterize by vacuum beds to work sheets of aluminium, composite, titanium, etc.
Special fabricated and weined steel bed frame with finish machinend, linear recirculating ball slideways on X axis. Double precision rack and pinion axis motion driven by brushless motor with a rapid travers rate of 60 m/1’.
Bridge type gantry assembly with cast structural beams that include finish machined, Y and Z axis linear recirculating ball slideways, precision rack (Y) and recirculating ball screws (Z). Motion driven by brushless motors with a rapid traverse rate of 60 m/1’ (Y) and 20 m/1’ (Z).
Valves for the manual operation: the vacuum base in made up of aluminium extruded beams that can be manually activated/deactivated by opening and closing the valves.
The machine is predisposed with an suction system that can be completed with an optional exhaust fan.
Ports USB, Lan.
