Fingertip joystick - TRY100

Professional Joysticks

Ask for a quote

Presentation

The TRY100 offers a wide variety of configuration options to cover a wide range of applications
The TRY100 is the all-rounder in the field of finger joysticks because of the extensive selection of handles, limiters and output options. It offers conventional handle designs as well as modern look and feel variants, in addition analogue outputs and digital interfaces. Redundant sensors are available as an option. This allows the joysticks to be optimized for almost any application.
With the convenient plug-in contact and the small installation depth of < 26 mm, the joystick offers unrivalled possibilities where space under the panel is limited. The construction is designed to withstand loads of up to 200 N, and improved handle options provide IP67 protection above the panel.
The joystick is available in different desktop variants with up to 5 push buttons.

Technical features

Technology: Hall effect,single-axis,2-axis,3-axis,contactless inductive Applications: industrial,remote control,medical,utility vehicles,aerial work platform,marine applications Other characteristics: with buttons,USB,fingertip,IP67,panel-mount,CAN bus Sensor technologyHall effect: Hall effect Output Linearity: ±200 mV Output Impedance: 2 Ohm Expected Mechanical Life: 5 million cycles Operating / Storage Temperature: -40 °C to +85 °C / -40 °C to +85 °C Voltage in Center Position: 2.5 V Max. vertical Load to Mechanism: 200 N (depends on handle)

Download the complete technical features
