The LPA900 - LPD1000 consist of ribbed steel panels, externally fixed to the secondary framing with self-drilling screws with composite nylon heads, coloured to match the sheeting.
Inside sheeting
Two inside sheeting options are available, LPI1200, and the1200 perforated LPG1000 for a pleasing interior finish and excellent sound absorption. Both panels hide the secondary framing.
Single skin wall with or without isobloc:
This system is the most economical
The insulation is made of soft faced glass fiber providing good acoustical comfort
It is available with Isobloc and increased insulation thickness to improve overall thermal performance and reduction of thermal bridges
Single skin wall with inside sheeting
Inside sheeting (LPI1200 or perforated LPG1000) can be fixed internally
• It includes all the advantages of the single skin wall with Isobloc
• The secondary wall framing is not visible offering a better inside view and aesthetic appearance
• In order to meet ultimate insulation requirements a second layer of insulation can be added to reach up to 0.3 W/(m2•K)
Double skin wall:
• This system offers the best possible insulation values up to a thickness of 160mm
• It includes all the advantages of the bridge solution
• The white faced internal liner panel provides a solid aesthetic appearance, acts as a vapour barrier and provides an improved fire rating over the faced insulation options
• Optional acoustic panels are available for increased noise absorption
