KIPP FRANCE

Toggle Locators 02000

Assembly systems and components

Ask for a quote Receive Documentation Contact the supplier

Material:

  • Body in tempered steel
  • ball in ball-bearing steel 1.2067
  • Form M: ball in tempered steel, insert with serration in hard metal

    Surface finish:

  • Body heat-treated and phosphated
  • ball hardened
  • Form M ball heat-treatet

    Note:

    Toggle Locators serve as stops, supports and thrust pads in fixture and tool shops.
    The serrated hard metal tips are soldered in. Ball is protected against torsion.

    * Only valid if the minimum borehole depth is observed
