Locking Bolts 03089

Material:

- Steel version, locking pin hardened:
quality class 5.8

- Stainless steel version, locking pin hardened:
threaded sleeve 1.4305
locking pin 1.4034

- Stainless steel version, locking pin not hardened:
threaded sleeve 1.4305
locking pin 1.4305

Mushroom knob in anthracite grey thermoplastic

Surface finish:

- Steel version, locking pin hardened:
black oxide finish, locking pin ground

- Stainless steel version, locking pin hardened:
natural finish, locking pin ground

- Stainless steel version, locking pin not hardened:
natural finish, locking pin ground

Note:

Locking Bolts are used to prevent any change in locking position due to lateral forces. A new locking position can only be set after the bolt has been manually disengaged.

Form C or D is recommended for applications in which gradual disengagement of the locking bolt is desired, without any relocking of the locking pin.

On request:

Special versions and spacer rings.
