TEMPRO plus D90 Temperature controller with touchscreen / thermoelectric / hot runner

Temperature regulator

“ Touch-Screen Series for Perfect Quality ”

Ask for a quote

Presentation

Latest design technology and operation …
In pressurized operation, a gauge ensures that the internal pressure is always 1 bar min. over the steam pressure curve.
Because of the smaller heat exchanger there is less circulating water. As a result, the preheating time and the cool down period have been reduced.

Optimum visibility and operation of the TEMPRO plus D
»» Touch-screen
The actual value and set point are displayed simultaneously.
»» Visual temperature control
The mold symbol color indicates if the temperature is in the
tolerance band (green: within tolerance; red: too hot; blue:
too cold).
»» Additional information on the display
The operator can choose an additional value to be displayed
on the screen (pressure, flow).
»» Easy operation with the TEMPRO plus D
Menus to adjust values and to choose operating modes can be
selected with color touch-screen.
»» Quick selection
Operating modes that are used frequently can be selected using the
touch fields at the bottom of the screen.

The TEMPRO plus D90 can work under temperatures running to 90°C and is an open system with dynamic, submersible pumps without pump seals. It also has a 5.7” touch-screen display and makes use of Windows CE. It also has a heat exchanger made of stainless steel integrated with incoloy heating element.
