Latest design technology and operation …
In pressurized operation, a gauge ensures that the internal pressure is always 1 bar min. over the steam pressure curve.
Because of the smaller heat exchanger there is less circulating water. As a result, the preheating time and the cool down period have been reduced.
Optimum visibility and operation of the TEMPRO plus D
»» Touch-screen
The actual value and set point are displayed simultaneously.
»» Visual temperature control
The mold symbol color indicates if the temperature is in the
tolerance band (green: within tolerance; red: too hot; blue:
too cold).
»» Additional information on the display
The operator can choose an additional value to be displayed
on the screen (pressure, flow).
»» Easy operation with the TEMPRO plus D
Menus to adjust values and to choose operating modes can be
selected with color touch-screen.
»» Quick selection
Operating modes that are used frequently can be selected using the
touch fields at the bottom of the screen.
The TEMPRO plus D series from Wittmann Battenfeld, is made available in various of models with different temperature operation capabilities. This apparatus is a pressurized machine consisting of powerful and magnetically coupled pumps. Moreover, it can handle temperatures of 140°C, 160°C up to 180°C.
