SS 63 mm Stainless Steel Conveyor

SS 63 mm Stainless Steel Conveyor - DORNER FRANCE

SS 63 mm Stainless Steel Conveyor - Heavy load chain conveyor

SS 63 mm Stainless Steel Conveyor - produit présenté par DORNER FRANCE

SS 63 mm Stainless Steel Conveyor

Heavy load chain conveyor

PCI digital output board with 32 outputs 24 or 5 V and optical isolation for a use in harsh environments. All the outputs are filtered and reset to « 0 » by Power-On. The watchdog is...

Ask for a quote

Presentation

The SS Conveyor is suitable for a wide range of applications either for horizontal or vertical product transportation.

Different Conveyor Chain Types
The SS multi-flexing conveyor systems uses a plastic chain that permits horizontal as well as vertical change of direction. In addition to the standard types, several special purpose chains are available. Take a look in the Tech Data located under Manuals & Literature for all options available. Please contact us or your local distributor for further assistance.

Technical features

Chain Width (mm) : 63 mm Tensile strength at 20ºC (N) : 4000 N Working temperature ºC : 20ºC – 60ºC Min. turning radius (mm) : 150 mm Max. working tensile at 20ºC (N): 500 N Link spacing (mm) : 25.4 mm Max. weight on conveyor (kg) : 150 kg Item width (mm) : 15-140 mm Max. item weight (kg) : 10 kg Chain weight (plain) (kg/m) : 0.75 kg/m
