GT STRUDL® | Structural Analysis and Design Modeling Software

CAD-Software

“ * Improve Productivity * Save time and increase profitability * Global package with international code rules * Quality Assurance * Steel & Concrete Structure Modeling * Advanced Analysis Methods * Interoperability w/ Smart solutions, CAESAR II® and CADWorx® Structure * International Design Codes ”

Ask for a quote

Presentation

GT STRUDL® is structural engineering software offering a complete design solution, including 3D CAD modeling and 64-bit high-performance computation solvers into all versions. GT STRUDL includes all the tools necessary to analyze a broad range of structural engineering and finite element analysis problems, including linear and nonlinear static and dynamic analysis, and can do so accurately in a fraction of the time of most other structural design software.

What is structural engineering software?

Structural design software helps structural engineers create safe and effective designs, while managing the complexity of many different scenarios across a range of industries, including power, civil engineering, marine and infrastructure. Quality software includes many features, such as interoperability, structural analysis, database-driven design and quality assurance - all of which are included in GT STRUDL.

How does structural engineering software work?

Structural engineering software helps streamline project execution, while being easy to learn and use. For example, GT STRUDL can create a usable analysis model from a flat CAD file, saving time and reducing manual errors. At the same time, structural engineers can also automatically generate wind and seismic loads in all user interfaces - reducing a intensive task to just minutes.

Technical features

Linear and nonlinear static and dynamic analysis Base plate modeling and analysis Multimaterial beam and FEA analysis Calculation of transfer forces per AISC Modern GUI, CAD, Wizards or Text input 64-Bit application that utilizes multiple processing cores Offshore structural analysis and design Management of all model data and analysis results Specification-driven design Reinforced concrete design

Download the complete technical features
