WITT Flashback Arrestors for reliable protection against dangerous reverse gas flow and flashbacks in accordance with DIN EN ISO 5175-1. Every Arrestor 100% tested.
The best Flashback Arrestors in the world
-
a large surface area flame arrestor FA of stainless steel construction extinguishes any dangerous flashback entering the device in any direction
-
a temperature-sensitive cut-off valve TV extinguishes sustained flashbacks long before the internal temperature of the arrestors reaches a dangerous level (not for FA E460)
-
a spring-loaded non-return valve NV prevents slow or sudden reverse gas flow forming explosive mixtures in the gas supply
-
a filter at the gas inlet protects the arrestor against dirt contamination, extending the service life
Operation / Usage:
-
Flashback Arrestors are used to protect gas cylinders and pipeline outlet points (hoses and any equipment) against dangerous reverse gas flow and flashbacks
-
for pipeline outlets and single cylinders with high-consumption users
-
WITT Flashback Arrestors may be mounted in any position /orientation
-
only one piece of equipment may be connected to a single Flashback Arrestor
-
the maximum ambient / working temperature is 70 °C / 158 °F
Maintenance:
-
annual testing of the non-return valve, body leak tightness and flow capacity is recommended
-
WITT is happy to supply special test equipment
-
Flashback Arrestors are only to be serviced by the manufacturer.
-
The dirt filter may be replaced by competent staff
Approvals:
Company certified to ISO 9001 and PED 2014/68/EU Module H
CE-marked according to PED 2014/68/EU
Cleaned for Oxygen Service according to EIGA IGC Doc 13/12/E: Oxygen Pipeline and Piping Systems
