ROEMHELD

Clamping Bars WZ 2.2096

Positioners and Tightening components

• For laser, motor spindles and plastics processing.• Including a fully hermetical cooling agent compressor for the cooling of clean water, glycol mix or emulsion.• A powerful water pump (WRK30-100...

Ask for a quote Receive Documentation Contact the supplier

Application
The clamping bars are used permanently installed on press beds and rams, on machines and plants for clamping and locking.

Description
The clamping bar is directly screwed on the press bed or ram using a spacer bar. Clamping is carried out on the die clamping edge by applying hydraulic pressure to the 2. 3 or 6 pistons which are arranged side by side with a pressure medium and mechanical unclamping by a spring return. Hydraulic oil is supplied through G 1/4 ports provided on both sides. Flat design with die inlet chamfer.

Advantages
? Piston stroke 8 mm
? Arrangement in series of several clamping bars with plug-in connectors
? Version with and without check valve
? Flat and compact design
? Fully resilient stroke limitation
? Easy installation
? Easy to retrofit

Download the complete technical features
