Weighbridge C85 HSDS

The C85 HSDS is a high-resistance low-profile above-ground weighbridge, fitted with a single-block concrete platform, that is designed to meet several or non-standard application requirements. It is highly robust and adapts to major dimensions. With a low-profile slab, its height remains low, which limits access ramp lengths. Moreover, stringers very efficiently act as dissuasive and non deformable wheel guides.
The C85 HSDS is particularly adapted to 50t to 100t capacities and specific lengths.

The metal framework is made up of IPE 500-type lateral beams, 2 end spacers and numerous intermediary spacers. The whole set can be either machine-welded and delivered in one piece in France entirely assembled in factory, or machine-bolted to be assembled on site, to facilitate transport by container. Casting is made onto a polyane film. The iron framework (slab truss) is entirely supplied by PRECIA MOLEN.

Dimensions

Capacity: 50 t to 100 t
Division: 20 kg to 50 kg,
Height: 350 mm (of which 90 mm of ground clearance).
