General data
sensing range: sd 0 ... 200 mm
reflector position: Sde 40 ... 200 mm
adjusting range reflector (operating range): ± 2,5% Sde
adjusting range reflector (limit range): ± 5% Sde
repeatability: < 1,5 mm
alignment aid target: display flashing
adjustment: Teach-in
temperature drift: < 2% Sde
response time: ton < 10 ms
release time: toff < 10 ms
sonic frequency: 380 kHz
output indicator: LED green
Electrical data
voltage supply range: +Vs 12 ... 30 VDC
current consumption: max. 35 mA
output current: < 200 mA
voltage drop: Vd < 2 VDC
residual ripple: < 10% Vs
short circuit protection: yes
reverse polarity protection: yes
Mechanical data
type: rectangular
housing material: polyester
width / diameter: 20 mm
height / length: 42 mm
depth: 15 mm
connection types: connector M8
Ambient conditions
operating temperature: -10 ... +60 °C
protection class: IP 67
