SPOT4Line A comprehensive, flexible solution for liquids in Industry

SPOT4Line A comprehensive, flexible solution for liquids in Industry - CHAUVIN ARNOUX

SPOT4Line A comprehensive, flexible solution for liquids in Industry - Spectroscopy

SPOT4Line A comprehensive, flexible solution for liquids in Industry - produit présenté par CHAUVIN ARNOUX

SPOT4Line A comprehensive, flexible solution for liquids in Industry

Spectroscopy

“ Reduction in cycle times with real-time correction of process parameters and drifts Reduction in non-compliance and product failures Decrease in energy consumption Decrease in raw material and solvent losses Decrease in waste and cleaning time ”

Ask for a quote

Presentation

Complex liquids can be found in many industries during manufacturing or cleaning operations (CIP).
To be controlled and identified, these products require measurement of both physical and chemical attributes. SPOT4Line is a new optical solution capable of measuring those attributes in real time, inside the process.

Know what you are doing in your pipe
SPOT4Line can help you save up to 15% in cleaning time while at the same time providing you a highly efficient solution to validate cleaning quality (safety).
Our solution helps you reduce cleaning time, use of cleaning agents, water consumption and energy use.
SPOT4Line can also accurately measure the color and turbidity level of your product which are very important sensory attributes for consumer markets such as beverages, detergents and paints.

A comprehensive, flexible solution for liquids in Industry

• Turbidity
• Optical density at 6 wavelengths: 75 nm, 465 nm, 525 nm, 595 nm, 625 nm, 860 nm
• Multi-angle design for very clear to highly turbid solutions
• Temperature

A design for industrial applications

• Very long service life without drift over time: LED technology
• Large measurement range: 1 to 10,000 NTU
• Optical density corrected from turbidity variations
• Operating T° range: -10 °C to 200 °C
• Operating Ph Range: 1 – 12

Technical features

21 CFR Part 11 compliance Full IQ/OQ/PQ support GMP compliance Optical density at 6 wavelengths: 75 nm, 465 nm, 525 nm, 595 nm, 625 nm, 860 nm Multi-angle design for very clear to highly turbid solutions Very long service life without drift over time: LED technology Large measurement range: 1 to 10,000 NTU Optical density corrected from turbidity variations Operating T° range: -10 °C to 200 °C Operating Ph Range: 1 – 12

Download the complete technical features
