SH7285

The SH7285 is a high-end single chip microcontroller incorporating an SH-2A core. The SH7285 incorporates 768KB or 512KB of Flash memory and operates at 100MHz. The SH7285 also incorporates register banks. When an interrupt occurs, CPU internal register information is stored in registers at high speed. This makes it possible to improve real-time control performance greatly. The SH7285 also incorporates various peripheral functions suitable for industrial application AC servos, general-purpose inverters and robots, such as a 1 channel USB2.0 Full Speed, a 5 channel serial interface, a multifunction timer unit, a 12-bit A/D converter,etc. The SH7285 realizes 5V single power supply and 3.3V single power supply operation despite operating at the high-speed of 100MHz.(Analog power supply is 5V)
