STÄUBLI ROBOTICS

SCARA robot TS2-40 HE

SCARA robot

“ To resist corrosion even under extreme conditions. ”
Ask for a quote Receive Documentation Contact the supplier


The TS2-40 HE robot is designed to resist corrosion even under extreme conditions. Its encapsulated design is ideal for various applications such as machine tool loading/unloading and food operations. Thanks to its drive technology, they achieve ultra-short cycle times.

ADVANTAGES OF THE TS2-40 HE

Hygienic design
  • Hygienic design aligned with EHEDG recommendations
  • Easy accessibility, cleanability and decontamination
  • NSF H1 compliant food oil with no loss of performance
  • No micro organic penetration due to design and pressurization

Stands up to extreme conditions
  • Fully encapsulated design (IP65)
  • Integrated user harness, tubing and valves
  • All connections protected under the base
  • Unrestricted pH suitability from 4,5 to 8,5
  • Kinematic pressurization for advanced tightness demands
  • Robust surface treatment/coating and stainless steel joints

Integration flexibility
  • Floor, wall and ceiling mounting possible
  • High dexterity in small workspaces due to compact integration of motors

Degrees of freedom : 4 Load capacity : 8.4 kg Reach : 460 mm Repeatability : ±0.01 mm Protection class : IP65 Mounting options : Floor, wall or ceiling Stäubli CS9 series controller

All industries Food industry Water jet cutting Machine tool loading/unloading Humid Environment
