Robots : MPL80

 The innovative, 5-axis palletising robot MPL80 with it´s payload of 80 kg is a dynamic masterful mover and stands out due to it´s extremely high acceleration and axis speed values. Another important criterion is the low space requirement.

The supply lines of the MPL models are routed internally (four air lines and 22 electric cables) up to the wrist axis, thus ensuring maximum service life of the hose packages.

Like all new MOTOMAN robot models, the MPL80 series is operated with the high-performance DX100 controller and can thus be equipped with all standard bus systems such as ASI-S. This bus cable can optionally also be routed internally through the robot as far as the wrist axis.

The MPL robots can optionally be delivered complete with a palletizing robot software package, specially tailored to the requirements of the customers. The software can be installed either on a PC or directly on the teach pendant.
