Planetary Mixer ARV 930 Twin Thinky

Planetary Mixer ARV 930 Twin Thinky - POLY DISPENSING SYSTEMS

Planetary Mixer ARV 930 Twin Thinky - Stirrers

Planetary Mixer ARV 930 Twin Thinky - produit présenté par POLY DISPENSING SYSTEMS

Planetary Mixer ARV 930 Twin Thinky

Stirrers

“ - First tank capacity of the range (1 Litre) - High power mixing function (660 G) - No material spillage during operation - Adjustable rpm allows optimal setting for any material - Cup holder vacuum system reduces pressure reduction time - High standard of deaeration for volatile materials ”

Ask for a quote

Presentation

Manufacturing application mixer that can vacuum process a maximum 1L of materials with twin mixer system.
This product employs a twin mixer system, and supports manufacturing application with the capacity to process a maximum 1L of materials.

It is equipped with a vacuum function in order to achieve deaeration at the submicron level, thus it is possible to process uniform mixing and dispersion as well as deaeration at the same time. It has two deaeration modes as standard features: one is vacuum deaeration mode which combines 400G centrifugal force and vacuum, and the other is Non Vacuum deaeration mode which utilizes powerful centrifugal force of maximum 670G.

This enables high precision deaeration even with materials that contain a volatile component that is not suitable for vacuum deaeration. Furthermore, time to reach vacuum is significantly reduced by adopting our unique in-cup-holder vacuum pressure reduction system that minimizes the vacuum volume.

Technical features

Max. processing volume 750 ml x 2 ou 550ml x 2 Dimensions H960 x L760 x P820 Max. weight ( net ) 830 g x 2 Max. weight ( brut ) 930 g x 2 Deaeration type Vacuum Mixing function 660 G RPM Adjustable
