Machine and Fixture Elements EH 2205

Assembly systems and components

“ Spring Plungers, with ball and slot ”

Ask for a quote

Presentation

Note:
To be used for locating or for applying pressure or lifting off.
Temperature range up to + 250 °C.

Material:

Body

Free cutting steel, blackened

Stainless steel 1.4305

Ball

Ball-bearing steel, hardened

Stainless steel, hardened

Spring

Stainless steel

Indication:

Free cutting steel finish with increased spring load = ball is yellow.
Stainless steel finish with increased spring load = body tip is yellow
