The base is in welded bent plate and is RAL 9002 painted.
It has an integrated electrical control board.
The system is certified as a “Class 1 welding system LASER”
for Nd:YAG ?=1064nm or CO2 ?=10.6?m sources in accordance with the laws in force regarding the safety of LASER emissions
(EN 12100-1, EN60825).
It has an aluminium plane, with an area of 600 x 500 mm², on the inside of the machining chamber for supporting the components to be machined, as well as threaded holes and pins for the rapid and precise fixing of the positions of the components.
It has an electrically servo-assisted vertical axis with a manual push-button control for the focalization of the LASER with a 400 mm stroke. Movement is on guide-ways and recirculating worm-screw operated ball-bearing trolleys. Lateral access is by way of a manually operated horizontal door.
More than 30 standard options are available, to guarantee the maximum flexibility of the system.
The inspection window on the lateral door is filtered for LASER emissions.
These machines, ideal for prototyping and mass production of small and precise components, can be equipped with a series of specific accessories for LASER marking: rotatingaxes, visual systems or controlled axes.
