“ • Chiller ready for connection • Air condensation • Evaporator of insulated tank immersion type or multi-tubular type • Complete hydraulic circuit: tank, pump, manometer, etc. • Coolant: R410A • Free-cooling on request • Heat recovery ”
Ice water unit designed for machine and process chilling. The device is loaded with coolant (R410A) and subjected to complete operational tests in the factory. Numerous optional extras: Stainless steel tank, 5 bar tank, anti-freeze resistance, desuperheater, etc.
– Frame: Made with electro-welded extra-thick steel tubes
– Panels: Painted steel RAL7035
– Compressor(s): Rotating (ENR 005) or scroll type (ENR 008 to ENR 480)
Evaporator(s):
Soldered stainless steel plate type (for ENR001/002)
Insulated buffer tank immersion type (ENR.003 to ENR100)
Multi-tubular type (ENR130 to 480)
– Air condenser: Battery of copper tubes and aluminium fins
– Fan(s): Helical, speed variation type (as of ENR 030)
Refrigeration circuit:
The refrigeration circuits are produced (according to model) with mono, bi or tri-compressor in
tandem configuration.
2 refrigeration circuits for 130 to 440 kW models
Main components:
Expansion capillary (according to model)
Thermostatic pressure-reducing valve (according to model)
Dehydrating filter
Liquid indicator (according to model)
Liquid solenoid valve (according to model)
HP/BP safety pressure switch(es) (according to model and optional extra)
HP/BP manometer(s) (according to models and optional extra)
Complete hydraulic circuit:
Carbon steel buffer volume (Fe 360)
2.5 bar pump
Enables operational inertia
Pressure-relief valve for pressurised circuit (according to model)
Water manometer (according to model)
Flow controller for evaporator protection (according to model)
Manual air vent valve (according to model)
By-pass (optional extra)
Regulation:
Basic electronic regulator with digital display (according to model and optional extra)
Microprocessor with digital display (according to model and optional extra)
