HITEMA chiller CSE series 30 to 370 Kw

HITEMA chiller CSE series 30 to 370 Kw - SOREMA

HITEMA chiller CSE series 30 to 370 Kw - Chillers

HITEMA chiller CSE series 30 to 370 Kw - produit présenté par SOREMA

HITEMA chiller CSE series 30 to 370 Kw

Chillers

“ • Centrifugal fans for air outlet sheathing • Evaporator of insulated tank immersion type or multi-tubular type • Complete hydraulic circuit: tank, pump, manometer, etc. ”

Ask for a quote

Presentation

The CSE ice water units are designed for an installation with sheathing of hot air extraction from the condenser. Water chiller with single-unit air condensation with centrifugal fan. Delivered ready for on-site installation.

Frame: With electro-welded extra-thick steel tubes

Panels: Aluminium

Compressor: Scroll type

Evaporator:
Tank immersion type (models CSE 30 to CSE 100)
Multi-tubular type (models CSE 130 to CSE 370)

Air condenser: Battery of copper tubes and aluminium fins

Ventilator:
Centrifugal type with pressure available at chiller outlet.
Outdoor condenser battery

Refrigeration circuit components:
Thermostatic pressure-reducing valve
Dehydrating filter
Liquid indicator
Liquid solenoid valve
High-pressure / low-pressure safety switch
High-pressure manometers & Low pressure manometers

Complete hydraulic circuit:
Pressurised buffer volume
Pressure-relief valve for pressurised circuit
Automatic air vent valve
Centrifugal pump
Automatic by-pass
Flow controller for evaporator protection
Water manometer

Regulation:
Basic electronic regulator with digital display (according to model and optional extra)
Microprocessor with digital display (according to model and optional extra)

Technical features

Centrifugal fans for air outlet sheathing Evaporator of insulated tank immersion type or multi-tubular type Complete hydraulic circuit: tank, pump, manometer, etc.
