Gas and air pumps: Vibrating Diaphragm Pumps 3000 series

Electric membrane pumps

“ • oil free • maintenance free • high pressure • long life ”

Ask for a quote

Presentation

References:

• SP 3300 LI

• SP 3500 LI

• SP 3800 LI

Motor:

• Power source [Vac] : 230 in 50Hz

• Power consumption [W]: from 12 to 24

Pneumatic performance:

• Free flow [l/h] : from 880 to 1250

• Max. pressure [bar] : from 150 to 270

• Max. vacuum [bar] : from -150 à -240

Linear Diaphragm Pumps: LI

Run by an electronic magnet, these pumps are spared the complexity of a motor driven technology. The linear pumps run completely frictionless. The outcome is an extremely high durability – ideal for continuous operations.

The product range contain a unique patented drive. This allows the linear pumps to reach an otherwise unobtainable pressure with an incredible performance.

Schwarzer Precision Linear Diaphragm Pumps are available as pressure (D) and vacuum-pressure (VD).
