CADWorx® Plant Professional

CAD, Design

“ * Auto-routing * Auto-Isometrics * Piping Specifications * AutoCAD® and BricsCAD® compatible * Ducting and Cable Trays * Collision Checking * Database Links * Equipment Modeling ”

Ask for a quote

Presentation

CADWorx® Plant Professional enables efficient plant design for greenfield and brownfield projects by providing a complete range of tools for creating intelligent 3D plant designs with DWG-based deliverables.

CADWorx offers unparalleled flexibility and productivity to help thousands of corporations execute projects and rapidly create cost-effective deliverables. By utilizing point cloud data in conjunction with the user-friendly CADWorx Plant Professional, executing brownfield projects becomes more accurate compared to traditional manual data collection methods.

CADWorx Plant Professional runs on AutoCAD® or BricsCAD® platform and includes BricsCAD® Pro, providing a complete package with powerful and adaptive tools that enable quick and easy creation of fully intelligent 3D plant models.

Technical features

• Intelligent 3D piping design • Specification-driven design • Dynamic pipe supports • Detailed bill of materials • Equipment Library Administration • Isogen® isometrics • Intelligent process diagrams • Model/P&ID synchronization • As-builts from Point Clouds • Links to Pipe Stress Analysis (CAESAR II)
