Automatic cutting and stacking machine for ISO cards : SYSCO - CAR-5N/5H

Plastic machining centre

Ask for a quote Receive Documentation Contact the supplier


  • Auto-cutting of plastic ISO cards from sheets of stacked and printed material.
  • Available for any commercial sheet format.

Features
  • A combination of high volume production, accurate die-cutting, and high quality card edges
  • Inboard & outboard ball screw servo-driven gripper unit with position accuracy of +/- 0.1mm
  • The shear type male & female die ensures excellent clean cut edges
  • The optical sensors with registration mark tracking system ensure a cut-to-print accuracy of +/- 0.1mm
  • A card stacking unit with 2 interchangeable magazines, each holding up to 450 cards with a thickness of 0.8mm
  • Scrap web is automatically discharged
  • The touch screen monitor makes the machine easy to operate
  • Complete CE safety guards
  • An air flotation system protects the cards from scratching during the feeding process
  • An auto sheet feeder with trolley holds approximately 1 000 sheets, with a sheet thickness of 0.8mm
  • Special accessories are available for thze accurate punching of contact-less plastic cards
Options
  • Larger size machine with more cavities is available upon request.
  • Sorting device allowing a specific punched rows of cards to be sorted into seperate magazines.

Cutting force : 5 tons Material size : 300Wx650L / 390Wx650L / 330Wx727L mm Format : 3x7 10 rows (horizontal) / 4x7 10rows (horizontal) / 5x7 10rows (vertical) Capacity : 11.000 - 32.000 cards/h

ISO card Plastic card Palying card Banking card
