Automatic cable reels- STEEL 900 RANGE

Electric roller

“ Level of protection IP65 Certified CE ”

Ask for a quote

Presentation

STEEL 900 :

- Case in painted steel and polymer
- Lateral fixation on 3 points
- Power colectors: 16-32-60-100 A
- Steel spring for a long lasting
- Level of protection IP65
- Delivered with cable H07RN-F, CF…
- Cable with 4 to 25 conductors
- Delivered with 2, 5 meters of cable on the supply side
- Use temperature - 5 °C/+50°C
- Maximum winding speed: 30 m/minute
- Collector isolation voltage 2.5 kV
- The cable should be fixed onto the mobile part to power (horizontal run) or on the floor (vertical run)

Given the technical nature of this range, it is strongly adviced to consult us to define, according to the intended use, the appropriate model and the necessary options.

Technical features

Case in painted steel and polymer Power colectors : 16-32-60-100 A Cable with 4 to 25 conductors Use temperature - 5 °C/+50°C Collector isolation voltage 2.5 kV

Download the complete technical features
