2-channel arbitrary function generators 40MHz, 80MHz, 120MHz | BK406xB

The BK4060B series 2-channel arbitrary waveform / function generators are capable of producing precise sine, square, triangular, pulse and arbitrary waveforms. This series combines the advantages of economical generators DDS, and, true arbitrary function generators (True Points).

They have been developed to meet a wide range applications that require high signal fidelity and low jitter arbitrary signal generation capabilities. The architecture of BK4060B series arbitrary waveform generator can switch between conventional DDS generator or true arbitrary mode.

Compared to the DDS generator, the implementation of the Arbitrary True Points mode provides better signal integrity by producing lower jitter and less distortion. All models are capable of generating 16-bit waveforms up to 300 MSa / s in DDS or 75 MSa / s in true arbitrary mode.

The intuitive touchscreen simplifies control of many features, including modulation schemes of extended waveform, linear / logarithmic sweep, burst mode and variable DC offset. These generators provide system integrators with the ability to auxiliary tripping and a reference clock of 10 MHz to synchronize multiple devices. 196 built-in arbitrary waveforms provide variety arbitrary test signals for simple applications and complex.

Generate custom arbitrary waveforms and download them to the device using the included application software. You can also use the drivers LabVIEWTM included to load data files from .csv or .txt waveform directly in the internal memory of the generator.
