Wire-actuated encoder SGH10

Features: 1 & 2 Pole relay range 40.31 - 1 Pole 10 A (3.5 mm pin pitch) 40.51 - 1 Pole 10 A (5 mm pin pitch) 40.52 - 2 Pole 8 A (5 mm pin pitch) PCB mount: - direct or via PCB socket 35 mm rail...

Ask for a quote

Presentation

The SGH wire-actuated encoder measures the absolute, direct cylinder stroke in the hydraulic cylinder. Cost-intensive drilling of the piston is no longer required thanks to the new measurement system. As a result there are lower integration costs compared with other measurement systems and weakening of the piston is effectively avoided. The highlight: The measurement system can even be used in telescopic cylinders!In the framework of SPS IPC Drives 2015, exhibition and online visitors nominated the SGH10 as the winner of the DirectIndustry i-NOVO Award in the TECH category. Measuring range 0 … 1000 mm. Absolute measuring system. CANopen interface, analog: Current and voltage. Operating voltage 9 ... 32 VDC. Pressure-resistant up to 300 bar, pressure peaks up to 500 bar. High degree of flexibility, adjustable to all measuring lengths thanks to teach-in . High electro-magnetic compatibility. High shock and vibration resistance.
