UV flatbed printer | UV 5530 +

Digital printing

The product holds 2 visible storage cabinets from series 550 or 290 which must be ordered separately. The unit includes a ball bearing base. The load capacity is 50 kg. The overall dimensions of a...

Ask for a quote

Presentation

UV5530+ is the smallest model in our range of UV printers.

It features a printing area of 295 x 550 mm, with a maximum height of 175 mm.

It is equipped with a DX5 head producing quality prints, immediately dried by a UV led lamp. Therefore printed item can be be handled immediately.

Its Whiterip professional Rip allows easy control t of printer and printing modes.

Printing technology : Ink jet (micro piezzo), 8 channel head - 180 nozzles / channel
Printing resolution : production mode 720 x 720 - 720 x 1440 - 1440 x 2880 - 1440 x 5760 dpi
Maximum printing sizes : 295 x 550 mm
Maximum printed part thickness (z axis) : 175 mm
Ink type : Flexible inks available in 500 ml or 1 L.
Colour configuration : Cyan, Magenta, Yellow, Black + White x 4 or Cyan, Magenta, Yellow, Black x 2 (2 x four colors)
Interface : USB
Electric supply : 100-240 VAC, 50-60 Hz / 4 A
Software : Supplied with White Rip for colour management.
