The GEBHARDT plug-in box

Pallet bags

Ask for a quote

Presentation

We offer an innovative solution that enables you to transport and store goods easily, safely and efficiently. The GEBHARDT plug-in box can be assembled into an export-ready box in just a few minutes. The simple plug-in system enables optimum, ergonomic loading from the front or the side. The structure of the pallet and the design of the inside of the box are customised depending on the load.

Variants of the GEBHARDT plug-in box incl. basic pallet
Basic dimensions of the 2-way pallet / external dimensions (LxWxH) / internal dimensions / payload

800 x 600 mm / 806 x 606 x 600 mm / 776 x 576 x 478 mm / 500 kg
1,140 x 760 mm / 1,146 x 766 x 761 mm / 1,116 x 736 x 639 mm / 1,000 kg
1,140 x 1,140 mm / 1,146 x 1,146 x 981 mm / 1,116 x 1,116 x 859 mm / 1,000 kg
1,200 x 800 mm / 1,206 x 806 x 909 mm / 1,176 x 776 x 787 mm / 1,000 kg
1,200 x 1,000 mm / 1,206 x 1,006 x 1,000 mm / 1,176 x 976 x 878 mm / 1,000 kg

Basic dimensions of the 4-way pallet / External dimensions (LxWxH) / Internal dimensions / Payload
1,140 x 760 mm / 1,146 x 766 x 786 mm / 1,116 x 766 x 639 mm / 1,000 kg
1,140 x 1,140 mm / 1,146 x 1,146 x 981 mm / 1,116 x 1,116 x 834 mm / 1,000 kg
1,200 x 800 mm / 1,206 x 806 x 934 mm / 1,176 x 776 x 787 mm / 1,000 kg
1,200 x 1,000 mm / 1,206 x 1,006 x 1,000 mm / 1,176 x 976 x 853 mm / 1,000 kg

Variants of the GEBHARDT plug-in box without base pallet
Strucutre for 4-way-pallet / External dimensions / Internal dimensions / Payload
1.200 x 800 mm / 1.206 x 806 x 962 mm / 1.176 x 776 x 802 mm / 1.000 kg
*The load must be secured appropriately on the base pallet. The truck payload and the DGUV regulations must be observed.

Pallets in standard design with top surface tightly laid
Other deck surfaces are also possible upon request

Technical features

Material: Plywood Payload: 500 - 1.000 kg Variants: 2-way pallet, 4-way pallet, without pallet Application: For storage of automotive parts, loads with special requirements Wood properties: Heat treated according to IPPC Product protection: Optimum protection of goods thanks to specially adapted interior
