Tank Cleaners – Compact lightweight type | ROTARY JETTER RJ series

Cleaning accessories

Ask for a quote

Presentation

Features

Low-pressure type rotating nozzle.
Solid stream jet provides high cleaning performance.
As the nozzle part is movable, it is easy to insert into and eject from a tank or equipment.
Compact design allows for installation in a tank with a small inlet.

*1) Spray capacity for each model:
RJ3-2-Φ7: 103 L/min (at 0.3 MPa, ca. 3 bar)–169 L/min (at 0.8 MPa, ca. 8 bar)
RJ3-2-Φ8: 127 L/min (at 0.3 MPa, ca. 3 bar)–207 L/min (at 0.8 MPa, ca. 8 bar)
RJ3-4-Φ6: 146 L/min (at 0.3 MPa, ca. 3 bar)–239 L/min (at 0.8 MPa, ca. 8 bar)

*2) Reach distance of RJ3-4-Φ6 is approx. 9 meter in radius.

Applications

Cleaning of tanks, chests, and containers, cleaning inside the chests (material tanks of papermaking)
