Shut-off and changeover valve : DCX3 DCX4

Shut-off and changeover valve : DCX3 DCX4 - DEFINOX SAS

Shut-off and changeover valve : DCX3 DCX4 - Regulation valve

Shut-off and changeover valve : DCX3 DCX4 - produit présenté par DEFINOX SAS

Shut-off and changeover valve : DCX3 DCX4

Regulation valve

Ask for a quote

Presentation

Its modular design makes interchanging components easy and provides a wide range of options and variants.
The DCX3 and DCX4 simple sealing changeover valves are fitted as standard with a floating PFA seal ensuring excellent cleaning of the valve.

From DN 25 to DN 150
PFA floating seal, perfectly cleanable, ensuring perfect leaktightness at high temperature and good resistance to chemical products
Spherical body with thick walls ensuring excellent resistance to expansion stresses
Different body configurations possible: + T L L/L T/L
Numerous end connections possible: SMS - DIN - Clamp
The plug can be supplied with an elastomer seal. Solution recommended for applications with charged liquids
Pneumatic actuator, removable and easily transformable: NO-NC-Double effect
Quick assembly and disassembly
Possible use on numerous applications
Complete interchangeability of the subassemblies
Easy and quick maintenance thanks to the clamp subassembly assembly.
