The M-16iB robot series offers a high flexibility for applications from 10 to 20kg payload. This series offers increased reach which makes them ideal for handling operations.
Maximum Payload : 10 kg
Maximum Reach : 1,885 mm
Repeatability : +/- 0.10
Axes : 6
Motion Speed :
J1 : 165°/sec
J2 : 165°/sec
J3 : 175°/sec
J4 : 350°/sec
J5 : 340°/sec
J6 : 520º/sec
Motion Range :
J1 : 340/360°
J2 : 250°
J3 : 460º
J4 : 400°
J5 : 280°
J6 : 900º
Applications : Painting / Coating , Glueing and Sealing , Arcwelding , Processing , Cutting , Assembly , Handling for Stamping and Forging , Handling for Die Casting , Handling for Plastic Moulding , Handling for Machine Tools , Others
