Analytics Semiconductor Vacuum solutions from a single source Our complete product portfolio at a glance Research & Development Complete solutions Pfeiffer Vacuum offers extensive solutions from a single source. A strong partner with a complete product portfolio. From consulting in the initial offer phase to the servicing of installed systems, Pfeiffer Vacuum stands for top quality products and services. Unique to Pfeiffer Vacuum is the combination of extensive technical expertise, high value products, competent advice and customer friendly service. ■ ■ ■  hether for vacuum generation, measurement, analysis, W leak detection, complete systems or components: the Pfeiffer Vacuum product portfolio offers the perfect solution to meet every need. Excellent quality and state-of-the-art technology are standard with all products. The complete range also includes extensive services: Our product training and other courses provide the technical basics of vacuum technology along with important information about the proper operation of our products in the real world. To best meet your requirements, we offer a broad range of consulting services. We work closely with you right from the planning stage to best meet your needs. In addition, we also offer information in the form of a full catalog, a vacuum technology compendium, and the Internet. Pfeiffer Vacuum describes the scientific principles of vacuum technology, offers technical details and provides vacuum expertise – perfect for both practice and research. Thanks to our service offices and our competent customer service, we can be on site quickly – anywhere, anytime. With repairs, support for independent maintenance, and product maintenance, we will help you – and only use genuine replacement parts. Vacuum solutions from a single source – professional, customer friendly and competent. Rotary/Linear feedthrough Electrical feedthrough Vacuum ­measurement, partial Vacuum chamber Turbo­ molecular pumps Vacuum ­measurement, total 10–13 hPa 10-12 hPa 10-11 hPa 10-10 hPa 1,000 km 10-9 hPa 10-8 hPa Roots pumps 10-6 hPa Medium vacuum 200 km 10-5 hPa 10-4 hPa 10-3 hPa Vacuum measurement, total 500 km 10-7 hPa High vacuum Vacuum measurement, total Ultra-high vacuum Extreme high vacuum l3 100 km 10-2 hPa 10-1 hPa 1 hPa 50 km Rotary vane pump Low vacuum 10 hPa Leak detector Gas analyzer 250 hPa 320 hPa 1,013 hPa Scroll pump Multi-stage Roots pump Example of a vacuum solution from Pfeiffer Vacuum’s product portfolio with an overview from low vacuum to ultra-high vacuum 0m
