Pneumatic Pump Dyna-mite Graco

“ - Extrusions of viscous fluid from a 0.95 to 3.79 L pot - Made of stainless steel. Compact and lightweight - High precision fluid dispensing - Robust design for the toughest conditions ”

Ask for a quote

Presentation

The Dyna-Mite pump 190 designed by Graco is the perfect solution for your small quantity applications, like glue or sealant in a container from 1 to 3 liters. The installation of a pump allows you to apply these products through a
distribution valve, either manual or automatic.

Its positive displacement process, operated by a priming piston facilitates the loading of a wide range of very viscous or pasty fluids, used in the assembly of precision parts.
The Dyna-Mite 190 pump is a compact, and lightweight pump that requires little work space and can easily adapt to a production line.

Made of stainless steel, the pump is quite solid and sturdy to withstand the toughest conditions in industrial work.

Technical features

Maximum fluid pressure output 6,0 MPa (60 bars) Air supply pressure range 243–700 kPa (2,4–7,0 bars) Maximum viscosity of the product 600 000 cps Stroke volume (distribution only on downstroke) 5 cc Advised in continuous operation regime 40 cpm Maximum pump speed recommended 60 cpm Race 19 mm Maximum operating temperature 60° C Weight Approx. 8,4 kg

Download the complete technical features
