The FANUC paint robot series is suitable for a wide range of painting and coating applications. They offer highest flexibility and precision to paint all sorts of materials such as plastics, metal, wood ...
Maximum Payload : 15 kg
Maximum Reach : 2,800 mm
Repeatability : +/- 0.5 mm
Axes : 6 (7th optional)
Motion Speed :
J1 : 96°/sec
J2 : 119°/sec
J3 : 150°/sec
J4 : 353°/sec
J5 : 429°/sec
J6 : 364°/sec
J7 : 1,500 mm/sec
Motion Range :
J1 : 210°
J2 : 150°
J3 : 160°
J4 : >360°
J5 : >360°
J6 : +/-720°
J7 : determined by rail length
Applications : Painting / Coating
